Product Description
Find the specifications for the Dell EMC PowerEdge R440 server:
Physical Specifications:
- Height: 1.69 inches (42.80 mm)
- Width: 18.97 inches (482.0 mm)
- Suitable with 6U Rack Server
Processors:
- Supports up to two Intel Xeon Scalable processors (1st or 2nd generation )
- Up to 22 cores per processor ( Current 1st gen)
Memory:
- 16 DDR4 DIMM slots
- Supports registered ECC DDR4 DIMMs (RDIMM/LRDIMM) ( Current 64 GB )
Storage:
- Front drive bays:
- Up to 2*8 (HDD/SSD).
- Maximum capacity: up to 48 TB
- Storage controllers:
- PERC H330, H730p, H740p, HBA330.
( Current - 1 TB )
Networking and I/O:
- Network daughter card options:
- 2 x 1 GE LOM (optional)
- 2 x 10 GE SFP+ or BaseT
- Front ports:
- Video
- USB 2.0
- USB 3.0
- iDRAC Direct USB
- Rear ports:
- Video
- Serial
- 2 x USB 3.0
- iDRAC network port
Power Supplies:
- Gold 450W *2 hot-plug power supplies with full redundancy
Management:
- iDRAC9 with Lifecycle Controller
- OpenManage Enterprise
- OpenManage Essentials
- OpenManage Mobile
Security:
- TPM 1.2/2.0 (optional)
- Cryptographically signed firmware
- Silicon Root of Trust
- Secure Boot
- System Lockdown
- System Erase
